WinOLS Map Pack - What is a Mappack in WinOLS?
A WinOLS mappack is a pre-defined collection of identified ECU maps that helps tuners locate and edit key parameters such as fuel injection, turbo boost, torque limits, and ignition timing without manually searching for them. Mappacks significantly speed up the tuning process, making modifications more efficient and accurate. The price of a WinOLS mappack varies depending on the ECU type, vehicle model, and seller, ranging from 95$ to several hundred euros, depending on the level of detail provided. The main advantages of using mappacks include faster tuning, reduced risk of errors, and better optimization of performance parameters, making them an essential tool for both beginner and professional tuners. Many tuners purchase WinOLS mappacks from specialized providers, ECU tuning forums, or create their own for future use.
WinOLS Mappack Download
If you're looking for high-quality WinOLS Mappacks, schiller tuning offers professional, well-structured tuning solutions for various ECUs. Our mappacks include essential tuning parameters such as fuel, ignition, boost, and torque limiters, ensuring precise and efficient remapping. If you are a tuner in need of a WinOLS Mappack, simply send us your original ECU file. After payment confirmation, we will prepare and deliver the mappack to you within a short time, ensuring a smooth and hassle-free experience.
WinOLS Mappack Price
Starting from $95 for a basic tuning table, which includes essential fuel, ignition, and boost maps for a standard performance upgrade. Advanced parameter mappacks, which provide deeper access to extended tuning features such as MAP sensor Scaling, MAF sensor voltage, Cylinder head temperature, Engine load limiter, Cooling Fan activation and special control strategies, can range up to $300. These advanced Mappacks are ideal for tuners seeking maximum customization and performance
e optimization. Pricing may vary based on ECU type, vehicle model, and specific tuning requirements.
How to Use a WinOLS Mappack (Video Tutorial)
Finding the right maps inside an ECU file is only the first step. Knowing how to correctly import, organize, and use a WinOLS Mappack is what makes the tuning process faster, safer, and more professional.
In the video below, taken directly from the Schiller Tuning WinOLS Training Course, we demonstrate the complete workflow of using a WinOLS Mappack inside WinOLS software. You'll learn how to load a Mappack, understand the identified maps, navigate through important calibration tables, and begin modifying ECU parameters efficiently.
Whether you're a beginner learning ECU remapping or an experienced tuner looking to improve your workflow, this tutorial will help you understand how professional tuners use WinOLS Mappacks in real-world calibration projects.
▶ Watch the video below to learn how to import and use a WinOLS Mappack inside WinOLS.
What is an A2L File?
An A2L file is a crucial component in the engine tuning process. A2L stands for "ASAM MCD-2 MC (Measurement and Calibration Data) - Description Language." It is a standardized file format used in the automotive industry to describe the measurement and calibration variables of Electronic Control Units (ECUs) in vehicles. These files provide detailed information on the parameters that can be adjusted to optimize engine performance, such as fuel injection timing, ignition timing, and more.
The A2L file organizes this information using a consistent format, allowing software tools to read and interpret the data efficiently. Typically, A2L files are created by ECU manufacturers or related engineering tools. Automotive engineers and technicians use them to calibrate and fine-tune vehicle systems during development and testing.
Calibration software and measurement tools can read A2L files to access the necessary measurement and calibration variables. These files contain important data such as memory addresses, scaling factors, and ECU-related information, all of which are essential for modifying the ECU software.
A2L files are commonly used alongside other tuning resources, such as mappacks or Damos files, to provide a comprehensive set of data for successful ECU remapping and optimization.
What Are WinOLS Damos files?
WinOLS Damos files, also known as A2L files, are detailed ECU map definitions that help tuners locate and modify specific parameters within an ECU file more easily. These files contain structured data, including map names, axis labels, conversion factors, and scaling information, making ECU tuning more precise. In WinOLS, a Damos (A2L) file can be imported to automatically recognize and organize maps, saving time compared to manual detection. WinOLS Damos price varies depending on the ECU type, availability, and supplier, as they are often sourced from official providers or tuning communities. To add Damos to WinOLS, simply open your ECU file, go to the import section, and load the corresponding A2L file, allowing for a smoother and more efficient tuning process.
What are WinOLS Scripts?
WinOLS scripts are automated commands used to apply predefined modifications to ECU files quickly and efficiently. These scripts help tuners make repetitive changes across multiple files, ensuring consistency and saving time during ECU remapping. Scripts can adjust parameters such as fuel injection, boost pressure, torque limits, and RPM limits automatically, making them especially useful for batch tuning or creating standardized tuning files. Using WinOLS scripts is a powerful way to optimize the tuning workflow, especially when working with multiple ECUs of the same type.
How to make scripts in WinOLS software?
1. Drag and Drop an original ECU file inside WinOLS
2. Find maps and apply changes to them
3. Press F8 and record all the scripts you did
4. Save and export the script
Let’s say you remapped an EDC17CP54, and then tomorrow another customer comes with the same car, you’re going to do all the map finding, editing like you did yesterday. You can instead save a script of the remap that you did and use it again when needed. This speeds up the remapping process a lot.
ECU Checksum correction
Checksum correction is crucial for verifying the integrity of data stored in the ECU's memory. The checksum is a value derived from the ECU's data (such as software, firmware, or configuration parameters) used to detect errors. When data is read or transferred, the checksum is recalculated and compared to the stored checksum. A mismatch indicates data corruption, which can be corrected using specialized algorithms and tools.
WinOLS Checksum: WinOLS software is a tool that can automatically correct the checksum after remapping the ECU. This is particularly useful for vehicle performance tuning.
Key points:
• Always use the original version of WinOLS to avoid errors or instability.
• A special plugin is required for each specific ECU model to ensure proper checksum correction.
Proper checksum correction is essential for maintaining the ECU's functionality and ensuring the reliable and safe operation of the vehicle.
Note: We also have a full article about checksum correction that we highly recommend you reading it for further information.
You can read the full CheckSam article
What is the difference between a Damos (A2L) file and a Mappack?
The main differences between Damos (A2L) files and Mappacks are:
• Damos (A2L) Files: These are OEM development files containing complete ECU data, including map definitions, axis descriptions, units, and functions. They provide full insight into ECU logic but require expertise to use effectively.
• Mappacks: These are pre-extracted and organized tuning map definitions, often customized for specific tuning needs. They are more user-friendly and focus on essential tuning parameters rather than full ECU structure.
In short, Damos/A2L files offer in-depth ECU data, while Mappacks provide ready-to-use tuning maps for practical tuning.
| Criteria | WinOLS Mappack | Damos (A2L) File |
|---|---|---|
| Definition | Pre-identified collection of tuning maps | OEM-grade ECU map definitions |
| Content Scope | Tuning-essential parameters only | Full system variables + logic functions |
| Ease of Use | High (Ready for immediate use) | Advanced (Requires architectural knowledge) |
| Customization | Limited to existing map definitions | Unlimited (Access to full ECU logic) |
| Primary Application | Routine performance remapping | Calibration engineering & R&D |
| Cost Basis | Affordable (Model/ECU specific) | Higher (Professional engineering data) |
WinOLS Mappack Generator
There is not a single software that can generate WinOLS Mappacks for your original ECU file. They only way to have a mappack for a certain ECU is to send the original file to ECU Tuning companies. Then a mappack is sent to you based on your needs. The thing is that a person with knowledge about WinOLS, finds every important table inside the ECU file, sorts them and gives them factors and offsets. Then the file is sent to you so you don’t have to spend time finding maps, and if you don’t have the knowledge, you can definitely learn from them too!
Bosch EDC16 WinOLS Mappack
The WinOLS Mappack for EDC16 ECUs includes essential tuning maps used for optimizing diesel engine performance. These ECUs are commonly found in VW, Audi, BMW, Mercedes, and other brands.
Common Tables in EDC16 Mappack:
1. Fuel Maps
2. Injection Timing Maps
3. Torque Limiter Maps
4. Boost Maps
5. EGR Maps
6. Smoke Limiter Maps
7. Rail Pressure Maps
These tables allow tuners to modify key engine parameters for power, efficiency, and emissions control.
Bosch EDC17 WinOLS Mappack
The WinOLS Mappack for EDC17 ECUs is essential for diesel engine tuning, commonly used in VW, Audi, BMW, Mercedes, and more. It provides access to key parameters for performance optimization.
Common Tables in EDC17 Mappack:
1. Fuel Maps
2. Injection Timing Maps
3. Boost Maps
4. Torque Limiter Maps
5. Rail Pressure Maps
6. EGR Maps
7. DPF Maps
8. Smoke Limiter Maps
9. Torque Monitoring Tables
The torque monitoring tables are also included in the Mappack, ensuring precise control and protection of the engine’s torque output.
Bosch ME17 & MED17 WinOLS Mappack
The ME17 and MED17 ECUs are used in a variety of modern vehicles, particularly those from Volkswagen Group (VAG), such as Audi, Volkswagen, and Skoda. These ECUs manage a range of engine parameters to optimize performance, efficiency, and emissions.
The WinOLS Mappack for ME17 and MED17 ECUs typically includes the following tables:
1. Fuel Maps
2. Ignition Timing Maps
3. Boost Maps
4. Torque Limiter Maps
5. Injection Maps
6. Lambda Maps
7. Driver Wish Maps
These tables are key for tuning performance, efficiency, and engine response.
Continental Simos series WinOLS Mappack
The Simos series ECU is a highly advanced system used in modern VW and Audi performance vehicles. Due to its complexity, the WinOLS Mappack we provide at Schiller tuning is more detailed than standard ECU mappacks, including precise small tables for deeper tuning control. Because of the advanced nature of this Mappack, the price is higher compared to other ECU mappacks.
Common Tables in Simos series Mappack:
1. Fuel Maps
2. Ignition Timing Maps
3. Boost Maps
4. Torque Limiter Maps
5. MAF Calibration Maps
6. Map Sensor Voltage Tables
7. Cylinder Head Temperature Tables
8. Gear-Specific Limiters
These advanced tables allow for precise adjustments, ensuring optimal power, efficiency, and engine safety.
WinOLS TCU Mappack
At Schiller tuning, we offer a specialized WinOLS Mappack for TCU (Transmission Control Unit), providing precise tuning for automatic and dual-clutch transmissions.
Specialized Tables in TCU Mappack:
1. Torque Limiters
2. Shift Timing Maps
3. Clutch Pressure Maps
4. Gear Ratio Adjustments
5. RPM Limiters
6. Launch Control Settings
7. Shift Speed Optimization
8. Oil pressure
These tables allow for smoother shifts, improved performance, and enhanced drivability, making our TCU Mappack an essential tool for transmission tuning.
Critical Mapping Parameters in Professional WinOLS Mappacks
| Map Group | Key Parameters included | Tuning Impact & Engineering Goal |
|---|---|---|
| Fuel & Injection | Duration, SOI, Rail Pressure | Optimizes combustion energy & power |
| Air & Boost | Boost Targets, VNT Control | Maximizes airflow and turbo efficiency |
| Torque & Limiters | Torque Limiter, Smoke Limiter | Protects hardware; manages output |
| Advanced Systems | EGR, DPF, Lambda, MAP Scaling | Ensures emission compliance & stability |
| TCU (Transmission) | Shift Timing, Clutch Pressure | Improves torque transfer & gear transitions |
Master Professional Remapping with Schiller Tuning
Understanding the software is only the first step; mastering the calibration strategy is what defines an expert tuner. Whether you prefer the streamlined efficiency of WinOLS Mappacks or the deep-level control of Damos files, we provide industry-standard training to help you unlock your full potential. Our comprehensive masterclasses are designed for enthusiasts and professionals who demand precision, safety, and performance. You can start your journey today by choosing the path that fits your goals:
- WinOLS Diesel Tuning Course: Master the art of diesel mapping and complex torque management.
- WinOLS Petrol Tuning Course: Dive deep into ignition timing, AFR optimization, and high-performance gasoline mapping.
- WinOLS Diesel DTC Course: Professional, permanent removal of diagnostic trouble codes.
- WinOLS DTC Petrol Course: Precise DTC management for petrol systems.
- Bosch Advanced WinOLS Course: Deep-dive into Bosch architecture for elite-level tuning.
Join the Schiller Tuning training program today to turn your technical knowledge into professional results.
Conclusion: Elevate Your Tuning Workflow
"In the world of ECU remapping, efficiency and precision are what separate amateurs from professionals. A WinOLS Mappack provides the speed and reliability needed for daily tuning, while Damos (A2L) files unlock the full engineering potential of an ECU for complex, custom calibrations. When paired with WinOLS Scripts and automated Checksum correction, these tools form the backbone of a high-performance tuning workshop.
However, software tools are only as effective as the tuner behind them. Understanding the raw binary data, identifying the correct maps, and knowing how to safely adjust limits are skills that take years to master or you can accelerate that journey with the right guidance.
At Schiller Tuning, we don't just provide files; we provide the expertise to help you master the architecture of any ECU. Whether you are seeking high-quality Mappacks or looking to master the WinOLS software itself, our team is committed to your professional growth.
Stop guessing, start engineering. Choose Schiller Tuning for professional-grade tuning solutions and industry-standard training."
