Petrol AFR vs Lambda / Everything About the Lambda Air/Fuel Ratio Chart

Gasoline AFR Explained

What does AFR stand for?

The air-fuel ratio (AFR) refers to the ratio of air to fuel in the combustion process of internal combustion engines. It’s a critical parameter for engine performance, fuel efficiency, and emission control. For example and AFR of 13:1 means 13 parts of air are mixed with 1 part of fuel by mass.

Air fuel ratio formula:

The air-fuel ratio (AFR) is the ratio of the mass of air to the mass of fuel in an engine's combustion mixture. The formula is:

                                                                                 AFR = Mass of Air / Mass of Fuel

For gasoline engines, the stoichiometric AFR (ideal ratio for complete combustion) is typically around 14.7:1, meaning 14.7 parts of air to 1 part of fuel by mass.

What is a stoichiometric AFR for Petrol?

It’s the ideal ratio where all the air and fuel combust completely without leaving excess oxygen or fuel.

For gasoline, the stoichiometric AFR is typically 14.7:1.

So is 14.7:1 the best AFR? Short answer, it’s best for both fuel economy and good torque in lower rpms and engine loads. But ideal AFR depends on lots of factors such as the type of fuel, turbo boost, quality of fuel, etc. This article focuses on the ideal AFR for petrol engines.

Rich Mixture (Low AFR): More fuel than the stoichiometric ratio

This AFR is a rich mixture which can produce more power but leads to higher emissions specially CO and NOx, which are very harmful for the environment. The richer the AFR the engine produces more CO emissions, lowers performance, lowers the combustion temperature and the more you go down the cars starts to produce black smoke. The point is that if you allow more fuel into the combustion chamber it doesn’t necessarily produce more power, it’s quite the opposite. Anything lower than 9:1 AFR for petrol engines can black smoke too.

Lean Mixture (High AFR): More air than the stoichiometric

You might think that I don’t need performance I just want to have more fuel economy so I’m going to tune my car to have a leaner AFR. There are things you should consider, most important one is that leaner AFR causes higher combustion temperature, higher exhaust gas temperature which can cause engine knock that destroys the engine in the long run. It causes the loss of performance and the increase of emission. But you might say, how is lean fuel going to create more emissions? It actually decreases CO but increases others like NOx and O2. Lean AFR can decrease emissions only to a point, after a point misfires can cause increase in HC instead of decreasing it and high EGT can cause NOx increases.

AFR vs Lambda for Gasoline engine

AFR:

It’s the mass ratio of air-fuel that differs for different type of fuel, for example the stoichiometric AFR for gasoline is 14.7:1 and for ethanol is 9:1.

Lambda:

It’s a dimensionless ratio that compares the actual AFR to the stochiometric AFR of a fuel. Lambda is independent of the type of fuel being used, making it a more general measurement.

 λ = Actual AFR / Stoichiometric AFR

We can say that:

λ = 1 → Stoichiometric mixture           λ < 1 → Rich mixture (excess fuel)         λ > 1 → Lean mixture (excess air)

Convert Lambda to AFR formula: How to calculate the AFR?

Lambda and AFR are connected through the stoichiometric AFR:

If λ=0.85 and the stoichiometric AFR is 14.7 then         →   AFR=0.85×14.7=12.5:1 (Rich mixture)         →  AFR=1.1×14.7=16.2:1 (Lean mixture)

lambda air/fuel ratio chart:

Petrol Lambda/AFR Chart indicates how different mixtures affect the engine. Starting from the top at WOT for turbocharged engines we need rich AFR to ensure no engine knocks and EGT safety. To reach the highest power for NA engines 12 to 13 AFR is best. Anything over the stoichiometric ratio which is 14.7 is considered lean and lowers performance and is not safe for engine and the exhaust system. The engine can work with up to a certain amount of lean AFR, after that there will be misfires, high HC and NOx emissions and the engine barely stays on.

 Rich AFR vs Lean: Is 16:1 rich or lean? Is 9:1 rich or lean?

As said before the 1 in the AFR is the fuel which is always the same. The thing that changes is the air ratio. This makes an AFR like 16:1 or λ=1.1 a lean mixture which can cause EGT to increase. In the other hand 9:1 is too rich to the point that it starts to produce black smoke.

What happens if AFR is too rich?

A rich mixture doesn’t burn all the fuel because there isn’t enough oxygen to combust it fully. This results in carbon build up on pistons, spark plugs and valves, which can reduce engine performance and cause misfires. A rich AFR increases emissions of unburned hydrocarbons (HC) and carbon monoxide (CO), which are harmful pollutants. This can lead to failed emissions tests and environmental concerns. Unburned fuel entering the exhaust system can overheat and damage the catalytic converter, leading to expensive repairs. To prevent this from happening you should do tune up the car on time. Be sure to change the sparkplugs on time, clean the fuel injectors. Also check the oxygen sensors and the MAF, MAP, MAT, sensors parameters inside the diagnosis device to make sure they’re working properly.

What happens if AFR is too lean?

A lean mixture burns hotter because there’s less fuel to absorb and dissipate the heat. These elevated temperatures can cause engine knocking (detonation), which is damaging to the pistons, valves, and cylinder head. We also have an article about engine knock which we recommend you to check out. While lean conditions can improve fuel efficiency slightly, they reduce the engine's power output because less fuel is being burned to generate energy. The engine may struggle under load or during acceleration. If the mixture is too lean the EGT gets so high that it melts the catalytic converter and the O2 sensors.

A lean AFR can result from several issues, such as faulty oxygen sensors or mass airflow sensors, a vacuum leak allowing extra air into the intake, incorrect ECU calibration or tuning, or a failing fuel pump or clogged fuel injectors. To prevent and address this, it’s essential to use proper tuning to maintain the AFR within the optimal range for the engine’s operating conditions. Regular maintenance of fuel and air delivery systems is also crucial, as is monitoring the AFR with wideband oxygen sensors during tuning and operation. A lean AFR must be resolved promptly to prevent long-term damage to the engine.

What should air/fuel ratio be at idle?

At idle the AFR should be close to 14.7 that is the ideal ratio for complete combustion with minimal emissions. Modern engines are all equipped with oxygen sensors and closed-loop fuel control systems that adjust the Lambda to 1. If you have a faulty O2 sensor you will fail the emission test because the sensor keeps it locked in closed loop to a certain RPM and the injection is limited to keep the CO emission under a certain amount.

What is the best AFR for fuel economy in petrol engines?

On paper 16 is the best but there are other things such as engine knock, fuel quality that doesn’t allow us to go over 14.7. However more modern cars with euro6 emission standards are more lean burn which makes them sensitive to low octane fuel.

What AFR is best for power? (petrol)

The Best AFR for a naturally aspirated engine falls in the rich range of 12.5:1 to 13:1. A slightly richer mixtures provides more fuel which cools the combustion chamber and reduces the risk of engine knock.

What is the best AFR for petrol turbo?

For turbocharged engines, the cruise area of the lambda table is set near the stoichiometric ratio (14.7) and the WOT is set to richer values to protect the catalytic converter, turbocharger, pistons, etc. We can set the high rpm/ high load areas to values like 11.5:1 to 12.5:1 to reach higher power. Be aware that for turbocharged engines, anything over 12:1 comes with the risk of overheating, high EGT, and engine damage overtime.

What AFR is good for WOT NA and Turbo?

At WOT, the ideal AFR for most naturally aspirated gasoline engines is around 12.5:1 to 12.8:1.
For forced induction engines (e.g., turbocharged or supercharged), a slightly richer AFR of 11.5:1 to 12.0:1 is typically used to account for increased cylinder pressures and temperatures.

In conclusion:

• For Naturally Aspirated Engines (NA): 12.5:1 to 13.0:1.
• For Turbocharged/Supercharged Engines: 11.5:1 to 12.0:1.
• Running too rich (below 11:1) may reduce power due to incomplete combustion, while running too lean (above 14:1) risks detonation and engine damage. Proper tuning is critical to optimize AFR for maximum power and engine safety.

What is the best AFR for torque in petrol engines?

Best AFR for Performance:

For naturally aspirated engines:

 the range of 12.5:1 to 13.0:1 provides the ideal balance of power, torque, and safety.

For turbocharged or supercharged engines:

  a slightly richer AFR of 11.5:1 to 12.0:1 is often used to manage the additional heat and pressure in forced induction systems.

Maximum Torque AFR (Gasoline): 12.5:1 to 13.0:1

Best AFR for Performance (Gasoline): The same range is typically best for overall performance, as torque and horsepower are closely related. Proper tuning in this range ensures optimal output while protecting the engine under high loads.
